AC SERVOMOTORS

SANYO DENKI offers a wide range of brushless servomotors with high performance and medium / low inertia. The available motors cover a power range from 100 W to 15 kW, with maximum torque up to 215 Nm. The motors, equipped with built-in incremental or absolute encoder for all versions and maximum speed up to 6000 rpm, are the most compact in the market and, coupled with proposed servoamplifiers, have an excellent dynamic behaviour and they are particulary suitable for applications with fast acceleration positioning at medium/high power.

DOWNLOAD AC SERVO SYSTEMS CATALOGUE


100x100!_r2aa04005_naname

48 VDC

Model name Nominal power (W) Normal speed (rpm.) Maximum speed (rpm.) Nominal torque (Nm.) Stall torque (Nm.) Maximum torque (Nm.) Inertia (Kg*m2) Encoder (imp./rev) Version with Gearbox
R2GD04005FXH1CM 50 3000 6000 0.159 0.167 0.54
0.0376*10-4
131072 (17 bit)
R2GD06010DXH11M 100 3000 5000 0.318 0.353 0.84
0.117*10-4
131072 (17 bit)
R2GD06020DXH11M 200 3000 4500 0.637 0.637 1.5
0.219*10-4
131072 (17 bit)
100x100!_purposes

230 VAC (BATTERY-LESS ABSOLUTE ENCODER)

Model name Nominal power (W) Normal speed (rpm.) Maximum speed (rpm.) Nominal torque (Nm.) Stall torque (Nm.) Maximum torque (Nm.) Inertia (Kg*m2) Encoder (imp./rev) Version with Gearbox
R2AA04010FXR1CM 100 3000 6000 0.286 0.318 1.18
0.0627x10-4
131072 (17 bit)
R2AA06020FXR11M 200 3000 6000 0.637 0.686 2.20
0.219x10-4
131072 (17 bit)
R2AA06040FXR11M 400 3000 6000 1.270 1.370 4.80
0.412x10-4
131072 (17 bit)
R2AA08075FXR11M 750 3000 6000 2.390 2.550 8.50
1.820x10-4
131072 (17 bit)
R2AAB8100HXR29M 1000 3000 3000 3.180 3.920 11.60
2.383x10-4
131072 (17 bit)
Q2AA10150BXR48M 1500 2000 2000 7.2 7.7 20.5
8x10-4
131072 (17 BIT)
Q2AA10150BCR48M 1500 2000 2000 7.2 7.7 20.5
8x10-4
131072 (17 BIT)
R2AA13200LXR00M 2000 2000 3000 9.5 12 24
12.2x10-4
131072 (17 BIT)
R1AA13300FXR00M 3000 3000 6000 9.7 9.7 29
7x10-4
131072 (17 BIT)
100x100!_100w

230 VAC (INCREMENTAL ENCODER)

Model name Nominal power (W) Normal speed (rpm.) Maximum speed (rpm.) Nominal torque (Nm.) Stall torque (Nm.) Maximum torque (Nm.) Inertia (Kg*m2) Encoder (imp./rev) Version with Gearbox
R2AA04010FXH1CM 100 3000 6000 0.318 0.318 1.18
0.0627x10-4
131072 (17 bit)
R2AA04010FCH1CM6 100 3000 6000 0.318 0.318 1.18
0.0627x10-4
131072 (17 bit)
R2AA06020FXH11M 200 3000 6000 0.637 0.686 2.20
0.219x10-4
131072 (17 bit)
R2AA06020FCH11M 200 3000 6000 0.637 0.686 2.20
0.219x10-4
131072 (17 bit)
R2AA06040FXH11M 400 3000 6000 1.270 1.370 4.80
0.412x10-4
131072 (17 bit)
R2AA06040FCH11M6 400 3000 6000 1.270 1.370 4.80
0.412x10-4
131072 (17 bit)
R2AA08075FXH11M 750 3000 6000 2.390 2.550 8.50
1.820x10-4
131072 (17 bit)
R2AA08075FCH11M 750 3000 6000 2.390 2.550 8.50
1.820x10-4
131072 (17 bit)
R2AAB8100HXH29M 1000 3000 3000 3.180 3.920 11.60
2.383x10-4
131072 (17 bit)
R2AAB8100HCH29M 1000 3000 3000 3.180 3.920 11.60
2.383x10-4
131072 (17 bit)
Q2AA10150BXH48M 1500 2000 2000 7.2 7.7 20.5
7.99x10-4
131072 (17 BIT)
Q2AA10150BCH48M 1500 2000 2000 7.2 7.7 20.5
7.99x10-4
131072 (17 BIT)
R1AA10150FXH00M 1500 3000 6000 4.8 4.9 15
2x10-4
131072 (17BIT)
R1AA10150FCH00M 1500 3000 6000 4.8 4.9 15
2x10-4
131072 (17BIT)
R2AA13200LXHW0M 2000 2000 3000 9.5 12.0 24.0
12.2X10-4
131072 (17 BIT)
R2AA13200LCHW0M 2000 2000 3000 9.5 12.0 24.0
12.2x10-4
131072 (17 bit)
R1AA13300FXH00M 3000 3000 6000 9.7 9.7 29.0
7x10-4
131072 (17 BIT)
R1AA13300FCH00M 3000 3000 6000 9.7 9.7 29.4
7x10-4
131072 (BIT)
100x100!_foto_r2ca18350_1

400 VAC (BATTERY-LESS ABSOLUTE ENCODER)

Model name Nominal power (W) Normal speed (rpm.) Maximum speed (rpm.) Nominal torque (Nm.) Stall torque (Nm.) Maximum torque (Nm.) Inertia (Kg*m2) Encoder (imp./rev) Version with Gearbox
R2CA18350LXR00M 3500 2000 3000 17.0 22.0 49.0
40x10-4
131072 (17 BIT)
R2CA18350LCR00M 3500 2000 3000 17.0 22.0 49.0
40x10-4
131072 (17 BIT)
R2CA18450HXR00M 4500 2000 3500 21.5 30.0 75.0
50x10-4
131072 (17 BIT)
R2CA18450HCR00M 4500 2000 3500 21.5 30.0 75.0
50x10-4
131072 (17 BIT)
R2CA18750HCR00M 7500 1500 3000 48.0 54.9 140.0
98x10-4
131072 (17 BIT)
100x100!_foto_r2ca18350

400 VAC (INCREMENTAL ENCODER)

Model name Nominal power (W) Normal speed (rpm.) Maximum speed (rpm.) Nominal torque (Nm.) Stall torque (Nm.) Maximum torque (Nm.) Inertia (Kg*m2) Encoder (imp./rev) Version with Gearbox
R2CA18350LXH00M 3500 2000 3000 17.0 22.0 49.0
40x10-4
131072 (17 BIT)
R2CA18450HXH00M 4500 2000 3500 21.5 30.0 75.0
50x10-4
131072 (17 BIT)
R2CA2215KVXH00M 15000 1500 2000 95.0 95.0 215
288x10-4
131072 (17 BIT)
