SERVOAMPLIFIERS

The wide range of R series Servoamplifiers produced by SANYO DENKI offers high quality and reliability in a compact size.
Important high-performance features, specifically designed for most thrusts motion control applications are built-in in
these systems.
All Servoamplifiers are CE / UL standards.

DOWNLOAD AC SERVO SYSTEMS CATALOGUE




100x100!_rf2g21aa

SERVOAMPLIFIERS 48 VDC

Model name Drive typoe Power supply voltage (Vac.) Safe Torque Off (STO) Max current (Amp.) Dimensions (mm.)
RF2G21A0AA0 STEP/DIR 48 VDC NO 40 30x116x70
100x100!_rs2k04a2ha5

SERVOAMPLIFIERS 48 VDC ETHERCAT

Model name Drive typoe Power supply voltage (Vac.) Safe Torque Off (STO) Max current (Amp.) Dimensions (mm.)
RSK04A2HA5 EtherCAT 48 VDC YES 40 40x160x85
RF2K24A0HL5 EtherCAT 48 VDC YES 40 50x200x130
100x100!_rs3a03a0alw00p_02

SERVOAMPLIFIERS RS3

Model name Drive typoe Power supply voltage (Vac.) Safe Torque Off (STO) Max current (Amp.) Dimensions (mm.)
RS3A03A0AL0W00 Step/Dir analog 230 NO 30 50x160x130
RS3A02A0AL2 Step/Dir analog 230 YES 20 40x160x130
RS3A03A0AL2 Step/Dir analog 230 YES 30 50x160x130
RS3A05A0AA2 Step/Dir analog 230 YES 50 85x160x130
RS3A10A0AA2 Step/Dir analog 230 YES 100 100x235x220
100x100!_rs3a03a2ha4w00p_laterale_

SERVOAMPLIFIERS RS3 EtherCAT

Model name Drive typoe Power supply voltage (Vac.) Safe Torque Off (STO) Max current (Amp.) Dimensions (mm.)
RS3A03A2HA4W00 EtherCAT 230 YES 30 50x160x130
RS3A05A2HA4W00 EtherCAT 230 YES 50 85x160x130
RS3A10A2HA4W00 EtherCAT 230 YES 100 100x235x220
RS3A03A2HAE (ADVANCED SAFETY) EtherCAT 230 Advanced safety function 30 60x160x130
RS3A05A2HAE (ADVANCED SAFETY) EtherCAT 230 Advanced safety function 50 105x160x130
RS3A10A2HAE (ADVANCED SAFETY) EtherCAT 230 Advanced safety function 100 120x205x220
100x100!_rs3c05a0aa2

SERVOAMPLIFIERS RS3C

Model name Drive typoe Power supply voltage (Vac.) Safe Torque Off (STO) Max current (Amp.) Dimensions (mm.)
RS3C05A0AA2 Step/Dir analog 400 YES 50 100x235x235
RS3C10A0AA2 Step/Dir analog 400 YES 100 175x235x235
RS3C15A0AL2 Step/Dir analog 400 YES 150 220x375x235
100x100!_rs3c05a2ha4

SERVOAMPLIFIERS RS3C EtherCAT

Model name Drive typoe Power supply voltage (Vac.) Safe Torque Off (STO) Max current (Amp.) Dimensions (mm.)
RS3C05A2HA4 EtherCAT 400 YES 50 100x235x235
RS3C10A2HA4 EtherCAT 400 YES 100 175x235x235
